Typhoon-Resistant Roof Design: One-Sided Roofs
1. One-Sided Roof Characteristics
Also known as: Mono-pitch, shed roof, or skillion roof
Description: Single sloping plane, usually with a steep pitch
Common uses: Modern architectural designs, additions to existing structures
2. Typhoon Resistance Considerations
2.1 Advantages
Simple design with fewer seams, reducing potential water entry points
Can be designed with a steep pitch for effective water shedding
Fewer edges for wind to catch compared to more complex roof shapes
2.2 Challenges
Large surface area can experience significant uplift forces in high winds
Asymmetrical design may lead to uneven wind loads on the structure
Potential for increased wind-driven rain penetration on the high wall
3. Design Recommendations for Typhoon Resistance
3.1 Pitch and Orientation
Optimal pitch: 30-45 degrees
Orient the low end towards the prevailing wind direction if possible
3.2 Structural Reinforcement
Use hurricane straps to secure roof to walls
Implement robust roof-to-wall connections, especially at the high wall
Consider using a structural ridge beam for added strength
3.3 Roofing Materials
Use impact-resistant materials (e.g., metal roofing, concrete tiles)
Ensure proper overlap and fastening of roofing materials
Install a fully-adhered underlayment for additional water resistance
3.4 Overhang and Edges
Minimize roof overhangs (ideally less than 50 cms/20 inches)
Use aerodynamic edge details to reduce wind uplift
3.5 Ventilation
Implement pressure-equalized soffit vents
Consider ridge venting systems designed for high-wind areas
3.6 Water Management
Install larger gutters and downspouts to handle heavy rainfall
Use multiple downspouts to distribute water flow
4. Additional Considerations
Ensure compliance with local building codes for high-wind areas
Conduct wind tunnel testing or computational fluid dynamics (CFD) analysis for complex designs
Consider the entire building envelope in the design, not just the roof
Regular maintenance and inspections are crucial for long-term performance
5. Alternative Roof Designs for Comparison
Hip roof: Generally considered more typhoon-resistant due to its sloped sides
Gable roof with low pitch: Can be vulnerable to uplift in high winds
Flat roof: Can be designed for high-wind resistance but requires careful detailing for water management
